Product Details
| Configuration |
| Material |
|
| Tube O.D. (in) |
3/8 |
| Dimension L (mm) |
42.7 |
| Series |
H-ZR |
| Dimension d (in) |
0.250 |
| Dimension L (in) |
1.680 |
| Dimension d (mm) |
6.35 |
| Dimension H (in) |
5/8 |
| Working Pressure (CU) (psig) |
3,300 |
| Working Pressure (CU) (bar) |
227 |
| Working Pressure (SS) (psig) |
3,300 |
| Working Pressure (SS) (bar) |
227 |
| ZCR Size (in) |
1/4 |
| Dimension d1 (in) |
0.310 |
| Dimension d1 (mm) |
7.90 |
| Working Pressure (NI) (psig) |
3,300 |
| Working Pressure (NI) (bar) |
227 |
